Air Monitoring
New Co2, Ch4 and Co Measurements for Hazardous Areas
Jan 28 2008
While the existing model has ranges of 0-10% and 0-25% for CO2, the latest offering provides ranges of 0-1%, 0-2.5%, 0-5% and 0-50% for CO2 and 0-5% for CH4 and CO. In addition, solvent-resistant variants of the analyser are available for CO2 measurement ranges of 0-1%, 0-2.5%, 0-5% and 0-10%, enabling analysis in natural gas where there are high levels of H25.
The 1900IR is suitable for use with flammable samples in Zone 1 hazardous areas (ATEX Category 2) without the need for a purge. Furthermore, Servomex has applied its infrared sensing technology in such a way as to give reliable, accurate results with low installation, maintenance and running costs. Accuracy is better than 1% FSR, response time (T90) is less than 10 seconds, repeatability is better than 1% FSR and zero drift is less than 1% FSR per week.
Typical applications will be found in natural gas processing, LNG and GTL plants - such as for monitoring pipelines, inerting, scrubbers and blending operations. Other opportunities exist in refineries, HyCO plants, ethylene plants, formaldehyde plants and VAM plants.
Ease of use is assured by virtue of the keypad-driven user interface. In addition, the analyser's casing is divided into two compartments, which enables the sample side compartment to be approved as intrinsically safe sample: significantly reducing the hazards present when working using a 'hot work permit'. On the other side the flameproof/explosion-proof terminals compartment enables the instrument to be located in hazardous areas without the need for a purge.
These features help to make the instrument economical to install, operate and maintain, resulting in a low long-term cost of ownership.
